12U Server Rack Double Section Wall Mount 19 Inch Network Cabinet

12U Server Rack Double Section Wall Mount 19 Inch Network Cabinet

19 Inch Network Cabinet

Wall Mount 12U Server Rack

Double Section 12U Server Rack

Place of Origin:


Brand Name:


Model Number:


Contact Us

Request A Quote
Product Details
Cold Rolled Steel
790*603*1000 Mm(H X W X D)
Powder Coating
Payment & Shipping Terms
Minimum Order Quantity
20 pcs
USD268.7—USD375.3 per pcs
Packaging Details
Carton box
Delivery Time
7-15 days
Payment Terms
L/C, D/P, T/T, Western Union
Supply Ability
5000 pcs per month
Product Description

12U Server Rack Double Section Wall Mount Ddata Cabinet Network Cabinet


This 12U Wall Mount Rack Enclosure Cabinet is designed to integrate wall-mounting, easy equipment

access, and cable management in IT network applications with limited floor space. Ventilated front

door and side panels allow generous airflow to keep equipment operating safely. Adjustable rack

rails with square mounting holes accommodate up to 12U of standard 19" rackmount equipment.

Supports up to 140 lbs of equipment. A sturdy hinge between the cabinet and the wall-mount

bracket allows the cabinet to swing away from the wall for easy access to equipment and cabling.

Top and bottom panels include convenient cutouts for cable routing.

Note: Image is for reference only and may not represent this exact model number.


  • 12U wall-mounted enclosure
  • Ventilated front door and side panels for increased airflow
  • Hinged cabinet swings away from wall bracket for easy equipment and cable access
  • Locking, reversible front door
  • Top and bottom panel cable access openings
  • Fully assembled for quick installation



  • Installed whole system maximum rack depth (inches) 32.7
  • Installed whole system maximum rack depth (cm) 83
  • Installed whole system minimum rack depth (inches) 3
  • Installed whole system total rack space height (rack spaces) 12U
  • Shipping weight (kg) 85.7
  • Shipping Dimensions (HWD/cm) 82 x 68 x 110
  • Unit weight (kg) 78.5
  • Unit Dimensions (cm) EXTERNAL DIMENSIONS: 79 x 63 x 102 (H x W x D)
  • Color Black
  • Weight Capacity - Stationary (lbs) 200
  • Grounding lug Front and Back door frames

Surface finish:

Degreaseing, Pickling, Phosphating, Powder Coated


Note: Depth can be customized (The standard depth should be 450mm and 600mm)


12U Server Rack Double Section Wall Mount 19 Inch Network Cabinet 0



Material Cold rolled steel
Size 780*600*1000mm
Surface treatment Powder coating
Pretreatment Degreasing
Color Black--Ral 9004
Main structure Welding
Lockable Yes
Custom Acceptable


1. After each batch of production, we will carry out strict load bearing experiments to ensure that we can

meet the customer's requirements --- FIG. 1

2. High density powder to ensure the appearance of the product --- FIG. 2

3. Proper packing will give the product the best protection against injury (The bubble bead + Carton +

paper Angle + PET strip + custom-sized pallet) --- FIG. 3


4. We work with a lot of logistics companies to get to any port --- FIG. 4



12U Server Rack Double Section Wall Mount 19 Inch Network Cabinet 1


This kind of double section network cabinet is popular in many countries. If your order quantity is large and

stable, you are welcome to be our distributor, so you can get more favorable price.
